Introduction

Seamless Copper tubes have an availability in the form of straight cut lengths in soft/ hard temper having various application plumbing, heatexchangers, solar, medical gas piping etc

spspsp

TEMPER

SOFT ANNEALED O60
HALF HARD- H55
HARD – H58

SIZES AVAILABLE

Range: OD: 4.76 mm to 50 mm
Thickness: 0.41 mm to 2.00 mm
Length:10 ft / 3.048 M

REFERENCE STANDARD

ASTM B280 (Product Availability Specified)
As Per ASTM B68, ASTM B75, EN1057, JIS H3300
IS 10773 Copper Tubes for AC & RF

SPECIFICATION CHART

VRF/VRV STRAIGHT PIPE (RR SHRAMIK)
InchmmThkWt. Of 10FtNo Of Pcs/BundleWeight Per Bundle (KG)Printing Matter
(RR BRANDED)
01/04″6.350.800.3810038.01RR SHRAMIK – VRV/VRF- COPPER
TUBE-IS 10773: 1995, GRADE-2(DHP),
SIZE OD._MM X W.T.MM,
HARD DRAWN – 100% EDDY
CURRENT TESTED –
HEAT No. MFG MONTH / YEAR
03/08″9.520.800.608047.78
01/02″12.70.800.826048.91
05/08″15.881.001.274050.96
03/04″19.050.801.253543.75
07/08″22.220.801.473044.01
1/00″25.40.881.892037.76
1-01/08″28.571.002.361842.49
1-01/04″31.751.102.971544.55
1-03/08″34.921.213.491345.40
1-01/02″38.11.324.161041.57
1-05/08″41.281.434.88839.03
1-03/04″44.451.605.87741.09
SizeWt. Of 10FtNo Of PCS/BundleWeight Per Bundle (KG)Printing Matter
(RR SHRAMIK)
VRF/VRV STRAIGHT PIPE (RR SHRAMIK)
SP-Od 9.52mm(03/08″)X0.70mm0.5298042.29RR SHRAMIK —
COPPER TUBE- IS 10773: 1995,
GRADE-2(DHP),
SIZE OD. MM X W.T. MM,
HARD DRAWN – 100%
EDDY CURRENT TESTED –
HEAT No., MFG
MONTH/YEAR –
SP-Od 9.52mm(03/08″)X0.90mm0.6646039.85
SP-Od 9.52mm(03/08″)X1.00mm0.7296043.77
SP-Od 9.52mm(03/08″)X1.20mm0.8555042.74
SP-Od 12.70mm(01/02″)X0.70mm0.7196043.15
SP-Od 12.70mm(01/02″)X0.90mm0.9095045.46
SP-Od 12.70mm(01/02″)X1.00mm1.0024040.07
SP-Od 12.70mm(01/02″)X1.20mm1.1824047.26
SP-Od 15.88mm(05/08″)X0.80mm1.0334041.32
SP-Od 15.88mm(05/08″)X0.90mm1.1544046.17
SP-Od 15.88mm(05/08″)X1.20mm1.5083045.25
SP-Od 19.05mm(03/04″)X0.90mm1.3993041.96
SP-Od 19.05mm(03/04″)X1.00mm1.5453046.36
SP-Od 19.05mm(03/04″)X1.20mm1.8342545.85
SP-Od 19.05mm(03/04″)X1.60mm2.3902047.81
SP-Od 22.22mm(07/08″)X0.90mm1.6432541.07
SP-Od 22.22mm(07/08″)X1.00mm1.8172545.42
SP-Od 22.22mm(07/08″)X1.20mm2.1602043.19
SP-Od 22.22mm(07/08″)X1.60mm2.8251542.37
SP-Od 28.57mm(1-01/08″)X0.80mm1.9022038.04
SP-Od 28.57mm(1-01/08″)X0.90mm2.1322042.64
SP-Od 28.57mm(1-01/08″)X1.20mm2.8121542.18
SP-Od 28.57mm(1-01/08″)X1.60mm3.6951244.34
SP-Od 34.92mm(1-03/08″)X1.60mm4.5641045.64
SP-Od 41.28mm(1-05/08″)X1.20mm4.1181041.18
SP-Od 41.28mm(1-05/08″)X1.60mm5.436843.49

APPLICATION

  • VRV and VRF – Air Conditioning and Refrigeration
  • Heat Exchangers – Chillers
  • Solar Equipments
  • Medical Gas Piping
  • Electrical Heaters
  • piping For Water Gas and Oil
  • General Engineering Purpose – Plumbing
